系統型號 | EV1005 | EV101 | EV202 | EV203 | EV204 | EV206 | EV207 | EV210 | EV210B | EV310 | EV220 | EV320 | EV222 | EV222B | EV322 | EV422 | EV232 | EV232B | EV432 | EV240 | EV240B | EV440 | EV250 | EV350 | EV450 | EV260 | EV360 | EV460 | EV370 | EV470 |
功放 | PA501EF | LPA102EF | LPA202EF | LA3K | LA4K | LA6K | LA7K | LA10K | LA20K | LA20K | LA30K | LA40K | LA50K | LA60K | LA70K | |||||||||||||||
臺體型號 | A005S12 | A01S12 | A02S12 | A03S15 | A04S15 | A06S20 | A07S23 | A11S24 | A11S34 | A11T24 | A20S32 | A20T32 | A20S34 | A20S44 | A20T34 | A20F34 | A30S34 | A30S44 | A30F44 | A30S34 | A30S44 | A30F44 | A50F44 | A50T44 | A50F44 | A50S44 | A50T44 | A50F44 | A70T45 | A70F45 |
額定推力(KN/kgf) | 0.55/55 | 1/100 | 2/200 | 3/300 | 4 /400 | 6 /600 | 7 /700 | 11/1100 | 202/2000 | 24/2400 | 22/2200 | 32/3200 | 40/4000 | 40/4000 | 40/4000 | 50/5000 | 50/5000 | 50/5000 | 60/6000 | 70/7000 | ||||||||||
沖擊推力(KN/kgf) | 1/100 | 2/200 | 4/400 | 6/600 | 8 /800 | 12 /1200 | 14 /1400 | 22/2200 | 40/4000 | 45/4500 | 44/4400 | 64/6400 | 80/8000 | 80/8000 | 80/8000 | 100/10000 | 100/10000 | 100/10000 | 120/12000 | 140/14000 | ||||||||||
頻率范圍(Hz) | 5-6000(10K) | 5-6000 | 5-4500 | 5-4500 | 5-4000 | 5-4000 | 5-4000 | 5-3000 | 5-3000 | 5-3000 | 5-2700 | 5-2500 | 5-3000 | 5-3000 | 5-3000 | 5-2,800 | 5-3000 | 5-3,000 | 5-3,000 | 5-3,000 | 5-2,800 | 5-2,700 | 5-2,500 | 5-2,800 | 5-2,700 | 5-2,500 | 5-2,500 | |||
最大正弦/隨機加速度 | 30/30 | 65/60 | 80/60 | 100/60 | 85/60 | 90/60 | 85/60 | 85/60 | 85/60 | 90/60 | 70/60 | 100/60 | 85/60 | 100/60 | 115/60 | 100/60 | 100/60 | 90/60 | 83/60 | 100/60 | 100/60 | 100/60 | 100/60 | |||||||
最大速度(m/s) | 1.6 | 1.8 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 1.8 | 1.8 | 1.9 | 1.8 | |||||||||||||||
最大位移p~p/(mm) | 20 | 25 | 40 | 51 | 51 | 76 | 51 | 76 | 51 | 51 | 76 | 100 | 51 | 100 | 51 | 51 | 100 | 51 | 76 | 100 | 51 | 76/63 | 100 | 76 | 100 | |||||
最大載荷 | 20 | 100 | 100 | 120 | 120 | 300 | 300 | 300 | 300 | 300 | 300 | 300 | 300 | 300 | 400 | 400 | 500 | 500 | 500 | 500 | 標準500(可選到2000 ) | 500 | 標準500(可選到2000 ) | 500 | 1 (可選2000 ) | 1 | ||||
動圈直徑 | 120 | 150 | 200 | 230 | 240 | 336 | 240 | 320 | 320 | 342 | 442 | 342 | 342 | 342 | 442 | 442 | 342 | 442 | 442 | 442 | 442 | 442 | 442 | 442 | 442 | 452 | 452 | |||
一階諧振頻率(Hz)(±5%) | 5,000 | 4,700 | 3,500 | 2,900 | 2,800 | 3,000 | 3,500 | 2,500 | 2,500 | 2,500 | 2,200 | 2,200 | 2,600 | 2,600 | 2,700 | 2,400 | 2,500 | 2,500 | 2,500 | 2,500 | 2,400 | 2,400 | 2,100 | 2,400 | 2,400 | 2,100 | 2,100 | 2,100 | ||
運動部件等效質量 | 1.7 | 1.5 | 2.5 | 3 | 4 | 6 | 7 | 11 | 13 | 24 | 24 | 24 | 25 | 30 | 30 | 30 | 35 | 30 | 30 | 35 | 50 | 55 | 60 | 50 | 55 | 60 | 63 | 70 | ||
冷卻風機 | 內置風機 | HB751 | B751 | B112 | B402 | B752 | B153 | B223 | B303 | |||||||||||||||||||||
風機功率 | 200W | 0.75kw | 1.1kw | 4kw | 7.5KW | 15kw | 22kw | |||||||||||||||||||||||
風機流量/風壓 | 2.3m3/min ;20kpa | 11m3/min ;2.11kpa | 23m3/min ;4.7kpa | 41m3/min ;2.6kpa | 82m3/min ;7.3kpa | 82m3/min ;8.5kpa | ||||||||||||||||||||||||
系統功率 | 1kVA | 3kVA | 4.6kVA | 6kVA | 7kVA | 17kVA | 18kVA | 23kVA | 42kVA | 42kVA | 56kVA | 56+20kVA | 75+20kVA | 85+30kVA | 95+30kVA |
